Clear hose with a black helix to allow visual inspection of media. Designed for use as primary, secondary & tertiary Air Seeder applications. This hose is quite flexible and enjoys an unsurpassed level of UV protection in its class. Hose conforms to AS/NZS 2070 (Plastics for food contact). Operating Temperature from -5°C to +60°C.
Clear hose with a black helix to allow visual inspection of media. Designed for use as primary, secondary & tertiary Air Seeder applications. This hose is quite flexible and enjoys an unsurpassed level of UV protection in its class. Hose conforms to AS/NZS 2070 (Plastics for food contact). Operating Temperature from -5°C to +60°C. Recommended Use: For dry conveying of seeds and grains in Primary, Secondary and Tertiary air seeder lines, can also be used for suction or delivery of water & other media.
Features
- PROUDLY AUSTRALIAN MADE.
- Conforms to AS/NZS 2070 (Plastics for food contact)
- Class leading wall thickness for longer in service life.
- Smooth bore to permit maximum flow.
- Operating temperature from -5°C to +60°C.
- Excellent Abrasion resistance
- Good Resistance to chemicals
- Softer Compound to protect seed and assist in ease of installation
- Class leading UV resistance.
Construction
Clear hose with a black helix to allow visual inspection of media. Smooth bore to permit maximum flow. Softer compound to protect seed and assist in ease of installation. Class leading wall thickness.
Applications
Designed for use as primary, secondary & tertiary Air Seeder applications. Recommended Use: For dry conveying of seeds and grains in Primary, Secondary and Tertiary air seeder lines, can also be used for suction or delivery of water & other media.
Specifications
| CODE | Nom ID | Nom OD | Working Pressure @ 20⁰C | Vac Rating *mm hg | Min Bend Radius | Stock Lengths |
|---|---|---|---|---|---|---|
| 36CB25X20 | 25mm | 31.9mm | .8mpa / 116psi | 550 | 120mm | 20m |
| 36CB32X20 | 32mm | 39.4mm | .7mpa / 101psi | 550 | 150mm | 20m |
| 36CB38X20 | 38mm | 46.1mm | .6mpa / 87psi | 550 | 200mm | 20m |
| 36CB44X20 | 44mm | 52.6mm | .6mpa / 87psi | 550 | 250mm | 20m |
| 36CB50X20 | 50mm | 60.2mm | .5mpa / 73psi | 550 | 300mm | 20m |
| 36CB63X20 | 63mm | 74.4mm | .5mpa / 73psi | 550 | 400mm | 20m |
| 36CB76X20 | 76mm | 89.6mm | .4mpa / 58psi | 550 | 450mm | 20m |
Specifications
| Hose ID | 25mm, 32mm, 38mm, 44mm, 50mm, 63mm, 76mm |
| Hose Length | 20m |
