Premium quality hose suitable for heavy duty industrial applications including air compressors & pneumatic tools. Manufactured from premium polymers to conform to AS/NZS 2554 Class B. Hose has great flexibility even at lower temperatures plus an abrasion resistant cover. This hose is UV Stabilised to suit extreme Australian conditions.
Features
- PROUDLY AUSTRALIAN MADE.
- Conforms to AS 2554 Class B
- Abrasion resistant high visibility blue and yellow cover.
- Excellent U.V. Resistance to withstand extreme Australian conditions.
- Good flexibility even at low temperatures.
- Designed for ease of movement without kinking.
- 10mm & 12mm Available fitted with quality Nitto style fittings.
- Operating temperature 5⁰C to + 60⁰C
- Manufactured with a 4:1 pressure safety factor.
Construction
Inner core: Flexible PVC with smooth finish. Reinforcing: High tenacity polyester yarn. Outer cover: UV stabilised high visibility blue PVC with yellow stripe with a smooth finish.
Applications
Multiflex Blue Yellow Air / Water Hose is ideal for use with air compressors and pneumatic tools. i .e. nail guns, rattle guns & staple machines etc.
Specifications
| Code | Nom ID | Nom OD | Working pressure @ 20⁰C | Stock lengths |
|---|---|---|---|---|
| 21MF6X** | 6mm | 12mm | 1.6mpa / 230psi | 20m, 100m & 300m |
| 21MF8X** | 8mm | 14mm | 1.6mpa / 230psi | 20m, 100m & 300m |
| 21MF10X** | 10mm | 16.4mm | 1.6mpa / 230psi | 20m, 30m, 100m & 300m |
| 21MF12X** | 12.5mm | 18.9mm | 1.6mpa / 230psi | 20m, 30m, 100m & 300m |
| 21MF20X** | 20mm | 27.9mm | 1.6mpa / 230psi | 20m & 100m |
| 21MF25X** | 25mm | 34mm | 1.6mpa / 230psi | 20m & 100m |
Specifications
| Hose ID | 6mm, 8mm, 10mm, 12mm, 20mm, 25mm |
| Hose Length | 10m, 15m, 20m, 30m, 40m, 50m, 60m, 100m, 200m, 250m, 300m, 1.5m, 12.5m, 55m, 65m, 70m |
| Customer Print (Multiflex Air Tool Hos) (Multiflex Air Tool Hose) | Able Air, Air Energy, Air Gun, Air Tool Services, Ash Air, Butters, Caps, Custom Print, Dixon, Fittings Express, Gasweld Toolex, Geiger, HS NZ, HSA, Hardie, Hose Fac, Hose Factory, Hose Shed, Hosetek, Hosfac, Ibex, James Street, Lawtools, MasterQ, MaxAir Blue, Multiflex, Multiflex Red, NCPS, Norosco, QTT, Rosscos Orange, Rural Quip, Super True Blue, Toolmart, Focus, Bayteck, IH&F |
| Fitting (Multiflex Air Tool Hos) | Fitted, Unfitted |
| Coupling Type (Multiflex Air Tool Hos) | ARO, BSP, Cejn, Nitto, None |
